Product Feature:
Frequency conversion (Electromagnetic valve speed control) feeder, full stainless steel with
overload protection device,equipped strong magnetic security device.Paddle/Impeller in the
conditioner, full stainless steel increased conditioning device ensure high quality of feed pellet.
The optimized pelletizing chamber structure ensures the that the pressing material is evenly
divided and maximizes the working potential of the pelletizer.
Main drive adopts high accuracy gearbox for high efficiency.
The ring die adopt anchorear type and disassembly is convenient.
Compace structure,easy operation,high output,long service life, less consumption,easy to use,
maintenance and quick. With oiling machine, Siemens motors，SKF bearings.
Advantages of Pellet Feed:
(1)The pelleting minimizes waste during the eating process,aviod animal picky eaters,
(2)The heat generated in conditioning and pelleting make the feedstuffs more digestible by breaking down the starches,
(3)Kill salmonella in feed,can protect the animal growth,
(4)Easy storage and transportation,liquidity is good,easy to manage.
Technical Parameter:
| Model | Power (kw) | Power of feeder (kw) | Power of conditioner (kw) | Inner diameter of ring die (mm) | Pellet size (mm) | Capacity(t/h) |
|---|---|---|---|---|---|---|
| SZLH 320 | 37/45 | 1.1 | 2.2 | 320 | 2-12 | 2-4 |
| SZLH 350 | 55 | 1.5 | 3 | 350 | 2-12 | 3-6 |
| SZLH 400 | 75/90 | 1.5 | 5.5 | 400 | 2-12 | 4-11 |
| SZLH 420 | 90/110 | 1.5 | 5.5 | 420 | 2-12 | 5-12 |
| SZLH 508 | 132/160 | 2.2 | 7.5 | 508 | 2-12 | 6-20 |
| SZLH 678 | 185/200 | 2.2 | 11 | 678 | 2-12 | 8-25 |
| SZLH 768 | 280/315 | 2.2 | 15 | 768 | 2-12 | 15-28 |
